Pardus Spark Disc Frameset

  • Sale
  • Dhs. 2,300.00
  • Regular price Dhs. 2,800.00
Tax included. Shipping calculated at checkout.


Spark is an aerodynamics series road bike, it has a small stack that could move the upper body's center of gravity forward and get better control. S and XS sizes have a smaller headtube angle and bigger fork offset which will bring a better trail. The BB drop of Spark is 68mm which brings good cornering stability  The geometry design of Spark makes sure the big size and small size all have cornering stability flexibility.

Spark geometry is not so aggressive, it is more friendly than Spark EVO, different sizes have different headtube angles, Seatpost has 0°and 25°offset options.

Specification

  • Frame: SPARK HS-EPS Carbon,12×142mm
  • Fork: SPARK, HS-HPT Carbon, 12×100mm thru-axle, Flat Mount Disc
  • Handlebars: PARDUS AL6061T6 double-butted,75mm reach,120mm drop
  • Seat Post: PARDUS SPARK,HS-EPS Carbon,-20mm/0mm offset,350mm,Di2-compatible

Package Include: Frame+Fork+Seatpost+Alloy Stem+Handlebar+Headset

Size Chart:

  • S: 160-170cm
  • M: 167-177cm
  • L: 174-182cm
  • XL:179-190cm

SPARK DISC - 105 Geometry

SIZE S M L XL
Size Chart(cm) 160-170 168-178 174-182 179-190
Reach 379mm 383mm 388mm 393mm
Stack 510mm 531mm 551mm 572mm
STR 1.36 1.39 1.42 1.46
Bike standover height 747mm 765mm 784mm 803mm
Top tube length(Horizontal) 520mm 535mm 550mm 565mm
Head tube angle 71° 72° 72.5° 73°
Seat tube angle 74.5° 74° 73.6° 73.3°
Wheelbass 996mm 990mm 997mm 1004mm
Chainstay length 415mm 415mm 415mm 415mm
Front center 591mm 585mm 591mm 598mm
BB drop 68mm 68mm 68mm 68mm
Seat tube length 459mm 476mm 495mm 512mm
Head tube length 115mm 130mm 150mm 170mm
Fork offset 53mm 45mm 45mm 45mm
Fork length 371mm 371mm 371mm 371mm
Trail 61mm 63mm 60mm 57mm
Stem length 90mm 90mm 100mm 100mm
Handlebar width 400mm 400mm 420mm 420mm
Crank length 170mm 170mm 170mm 172.5mm
Seat tube offset -20/0mm -20/0mm -20/0mm -20/0mm
