Go hybrid Pardus Legend Sport
Specification
- Frame: LEGEND SPORT,AL6061 T6 Aluminum,Post Mount,35×5mm Quick Release
- Fork: LEGEND SPORT,AL6061 T6 Aluminum,Post Mount,100×5mm Quick Release
- Shifter: shimano ALTUS M315,3×8 speed
- Front derailleur: shimano ALTUS FD-TY710
- Rear derailleur: shimano ALTUS RD-M310-Smart,32T MAX
- Crank: PROWHEEL SWIFT-201P,48-38-28T
- Cassette: shimano HG200-8
- Chain: KMC Z8
- Bottom Bracket: BB73-68mm,BSA,Sealed Cartridge
- Brake: shimano MT200 Hydraulic Disc Brake
- Wheel: PARDUS PR-27 Aluminum DISC RIM,700c,27mm rim width,18mm rim depth,6 bolt, front 100×5mm Quick Release, rear 135×5mm Quick Release
- Tire: KENDA K1257 700×32c
- Saddle: PARDUS 145×250mm
- Handlebars: MVMT M-BLACK AL6061 T6,5 degree,31.8mm
- Stem:MVMT M-BLACK AL6061 T6 3D forged and CNC +7°
- Seat Post: MVMT M-BLACK AL6061 T6 3D forged 15mm Offset,30.9X350mm
- Weight: 12.5kg
| LEGEND Geometry | ||||
| Size | XS | S | M | L |
| Reach | 360 | 375 | 388 | 400 |
| Stack | 555 | 580 | 599 | 620 |
| Bike standover height | 770 | 787 | 808 | 830 |
| Top tube length(Horizontal) | 509 | 536 | 560 | 578 |
| Head tube angle | 69.5 | 70 | 70 | 71 |
| Seat tube angle | 75 | 74.5 | 74 | 74 |
| Wheelbass | 1029 | 1048 | 1068 | 1077 |
| Chainstay length | 445 | 445 | 445 | 445 |
| Front center | 594 | 613 | 632 | 642 |
| BB drop | 70 | 70 | 70 | 70 |
| Seat tube length | 460 | 480 | 500 | 520 |
| Head tube length | 115 | 140 | 160 | 180 |
| Fork offset | 45 | 45 | 45 | 45 |
| Fork length | 422 | 422 | 422 | 422 |
| Stem length | 60 | 60 | 70 | 70 |
| Handlebar width | 640 | 640 | 640 | 640 |
| Crank length | 170 | 170 | 170 | 172.5 |
| Seat tube offset | -15 | -15 | -15 | -15 |
