Extraordinary stiffness is the key to standing out
The SPARK RS uses HS-grade carbon fiber materials and EPS+latex disappearing mold molding technology to achieve formidable five-way stiffness, providing power for every powerful sprint.
Aggressive geometry for easier access to extreme speed
The SPARK RS has the same geometry and the spark Evo series is designed for the race track, with an aggressive riding style and a low STR value. This makes it easy to maintain a low center of gravity riding posture. The new generation SPARK RS changes the design of the bowl set cover, and appropriately increases the STACK value while adjusting the overall geometry layout, maintaining an aggressive riding posture and improving comfort. The new XXS size is added, and the REACH value is only 365mm, which is more friendly to users with low height.
Integrated simplicity with fully hidden internal routing
The MVMT M-Silver A-Type handlebar realizes full hidden internal routing, with a flat aerodynamic section and a forward extension design, further improving the aerodynamic effect.
Specification
- Frame: SPARK HS-EPS Carbon,12×142mm
- Fork: SPARK, HS-HPT Carbon,12×100mm thru-axle, Flat Mount Disc
-
Shifter: SRAM Rival eTap AXS 12-speed
- Front derailleur:SRAM Rival eTap AXS D1,braze-on,2×12 speed
- Rear derailleur: SRAM Rival eTap AXS D1 12 speed
- Crank: SRAM Rival eTap AXS D1,48-35T
- Cassette: SRAM RIVAL XG-1250,10-30T, 12-speed
- Chain: SRAM RIVAL D1,12speed, Power Lock
- Bottom Bracket: SRAM BB DUB PF30 ROAD68
- Brake: SRAM RIVAL e-Tap AXS D1 Hydraulic Disc Brak
- Brake Rotor: SRAM RT-Centerline-A2,Center Lock,F & R160mm
- Saddle: Selle Italia Model X
- Wheels: PARDUS PW3 DB, Aluminum, Center Lock, Tubeless Ready,25mm rim width,27mm rim depth, front 100×12mm; Rear SRAM XDR freehub,142×12mm thru-axle
- Tire: Continental Grand Sport Race 700*25C
- Handlebars: MVMT M-SILVER A-TYPE Carbon, Integrated Handlebar,72mm reach,130mm drop
- Seat Post: PARDUS SPARK EVO, HS-HPT Carbon,0mm offset,350mm, Di2-compatible
- Weight: 8.5kg in the S size
Geometry:
| SIZE | XXS | XS | S | M | L | XL |
| Reach(R) | 365mm | 372mm | 379mm | 383mm | 387mm | 398mm |
| Stack(S) | 497mm | 507mm | 517mm | 527mm | 540mm | 565mm |
| STR | 1.36 | 1.35 | 1.36 | 1.37 | 1.39 | 1.41 |
| Bike standover height | 733.7mm | 743mm | 754.5mm | 764.3mm | 779.1mm | 803mm |
| Top tube(B) length(Horizontal) | 493.5mm | 507.9mm | 519.5mm | 530.2mm | 541.8mm | 562.1mm |
| Wheelbase (E) | 958.3mm | 968.5mm | 970.1mm | 972.8mm | 977.1mm | 995.5mm |
| Chainstay length(F) | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm |
| Front center(G) | 559.9mm | 570.1mm | 571mm | 573.7mm | 577.4mm | 595.7mm |
| BB drop(H) | 74mm | 74mm | 72mm | 72mm | 70mm | 70mm |
| Seat tube length(I) | 453.8mm | 463.7mm | 473.6mm | 484mm | 497.4mm | 522mm |
| Head tube length(J) | 90mm | 100.5mm | 109.8mm | 118.5mm | 132.5mm | 158.6mm |
| Fork offset (K) | 50mm | 50mm | 45mm | 45mm | 45mm | 45mm |
| Fork length （L） | 370mm | 370mm | 370mm | 370mm | 370mm | 370mm |
| Trail | 58.7mm | 58.7mm | 58.7mm | 58.7mm | 58.7mm | 58.7mm |
| Stem length | 80mm | 90mm | 100mm | 110mm | 110mm | 120mm |
| Handlebar width | 380mm | 380mm | 380mm | 400mm | 420mm | 420mm |
Size Chart:
- XXS: 150-160 cm
- XS: 157-166 cm
- S: 163-173 cm
- M: 168-178 cm
- L: 176-186 cm
- XL: 182-195
